Create speedometer chart

To create a speedometer chart, you need to prepare some data at first.

1. Please specify the value range and parts you want the speedometer chart shown. Here I will separate the speedometer to three parts, so I will type 30, 60, 90 into three cells, then in the cell below them, type the total number of numbers you typed in the above three cells. See screenshot:

2. Go to the blank range next to the Value column, and type with below data. See screenshot:

Tip: In the Cell D4, type this formula =360-(D2+D3).

3. Select data in Value column and click Insert > Other Charts > Doughnut.

In Excel 2013, click Insert > Insert Pie or Doughnut Chart.

4. Right click at doughnut to select Format Data Series in context menu, then in Format Data Series dialog/pane, type 271 into Angle of first slice textbox.

5. Close dialog, right click at the biggest point, and click Format Data Point in context menu.

6. In the Format Data Point dialog, click Fill > No fill, and close the dialog.

In Excel 2013, click Fill & Line > No fill in Format Data Point pane.

7. Right click at the doughnut to select Select Data from context menu. Then in the popping dialog, click Add button.

8. In the Edit Series dialog, specify the new series name and select the series values.

9. Click OK > OK to close dialogs. And right click at the second doughnut (the outside one), click Change Series Chart Type, then in the Change Chart Type dialog, click Pie > Pie, and click the OK button to close the dialog.

In Excel 2013, under All Charts tab and in Combo section, click Pointer series, and click Pie in the drop down list, then check Secondary Axis box, and click OK to close this dialog.

10. Then click at the pie chart, and right click to select Format Data Series to go to Format Data Series dialog, and check Secondary Axis option, and then type 270 into the Agle of first slice textbox, and close the dialog.

In Excel 2013, type 270 into the Agle of first slice textbox in Format Data Series pane.

11. Select only the biggest point of pie, and right click to select Format Data Point. See screenshot: Rainbow six siege designer notes.

12. In popping dialog, click Fill > No fill, and close the dialog.

In Excel 2013, click Fill & Line > Fill > No fill in the pane.

Then repeat this step to remove fill color of the bigger one in pie. Then you can see the chart shown as below:

13. Click at the pointer, and right click to select Add Data Labels, then click the appeared label, and click it again to edit it. Type = into the formula bar, and then select the cell you have typed 10 into it in step 2.

14. Press Enter key. Now when you change the cell content in cell D2, the pointer will auto change.

And you can format the chart as you like.
